HLG-480H operates from 90 305VAC and offers models with different rated voltage ranging ~ between 24V and 54V. Thanks to the high efficiency up to 95.5%, with the fanless design, the entire series is able to operate for -40 ~ +90 ℃ ℃ case temperature under free air convection.

The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications.HLG-480H is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.

Specifications

Part Number:
HLG-480H-24
Manufacturer:
MEAN WELL
Power:
480 W
Vin_min:
90 VAC
Vin_max:
305 VAC
LED Driving Mode:
Constant Current, Constant Voltage
Dimming:
Non-Dimming
Iout_min:
20000 mA
Iout_max:
20000 mA
Vout Min:
12 V
Vout Max:
24 V
Case:
Metal Enclosure
IP Rating:
IP67
PFC:
PFC
% Typ Efficiency:
94
Certifications:
UL8750, CSA C22.2 No. 250.12-13, ENEC EN61347-1, EN61347-2-13, EN62384, GB19510.14, GB19510.1, EN55015, EN61000, GB17743, GB17625.1, EN61547
Special Note:
7-Year Warranty, Cable for I/O
Outputs:
1-Output

Downloads

Download Data Sheet
