Features / Specifications

• Low Profile Design
• Surface Mounting
• ECE Approved
• IP67 Rated
• 12 Volt or 12-24 Volt
• 281mm x 101mm x 30mm
• 5 Year Warranty

Fitting Instructions

Horizontally mount the bracket onto a flat surface with screws provided, ensuring TOP markings are positioned above centre holes. Remove backing from 3M tape on the back of the lens, run wires through the desired centre hole and align the locator nodule on the edge of the lens with the corresponding indentation on the bracket. Apply firm hand pressure to ensure lamp adhesion. Repeat for each lens until all are installed securely. Refer to ADR 13/00 for mounting instructions.

Technical Drawings
