Introducing the BASE6 4 LED Amber Perimeter Light, a top choice for those seeking superior visibility and durability. This high-performance light features an innovative angled design for enhanced off-axis visibility, ensuring maximum safety and awareness. Its robust alloy housing and cutting-edge LED technology make it a reliable, maintenance-free solution for any vehicle.

Key Features and Specifications

BASE6 2-Year Warranty

• Dimensions: 91mm (L) x 23mm (W) x 15mm (H)
• LEDs: 4 Ultra-High Intensity LEDs
• Flashing Patterns: 19+ user-selectable options
• Improved Visibility: Advanced off-axis performance with unique directional reflector optics
• Daytime Performance: Exceptional brightness for all-day use
• Housing: Low profile, heavy-duty alloy construction
• Synchronization: Capable of synchronizing multiple units
• Maintenance-Free: 100% solid state design with no moving parts

Wiring Configuration

• BLACK: Negative ground wire
• RED: Positive wire
• YELLOW: Pattern select (positive trigger) and synchronize function
• WHITE: Simultaneous or alternating flash

Technical Specifications

• Current Draw: 1amp @12vdc / 0.5amp @24vdc
• Certifications: R65, SAE Class 1 & 2, SAE J595
• Voltage: 10-30 multi voltage ready
• Durability: IP69K rated for dust, vibration, and water resistance (highest in the market)
• Temperature Range: Operates efficiently from -40˚C to +60˚C
• LED Lifespan: 100,000 hours with long-life LEDs

Elevate your vehicle's safety and performance with the BASE6 Amber 4 LED Perimeter Light. Its unmatched reliability and advanced features make it the ideal choice for any application.
